Behringer P24 StageConnect Personal Monitor Mixer
$369.00
ⓘ Product ETA: 01/07/2025
Pay with
Afterpay Popup
StageConnect Personal Monitor Mixer with 13 Stereo Channels and 60-mm Faders
Having a dedicated monitor mix engineer can be expensive and running monitor mixing from FOH can be too demanding-- neither of these is ideal. What if every musician could create their personal monitor mix with a small dedicated mixer on-stage? That's what Personal Monitoring is all about!
Save time and energy by giving the control to the musicians! Personal monitors also allow for built-in effects, improving sound; built-in microphones, improving both communication and immersion; All controlled with a simplified user interface.
Features
- An intuitive personal monitor mixer and talkback solution for StageConnect-equipped devices
- 60mm faders provide hands-on control
- 12 stereo groups and 1 local aux input ensure straightforward personal mixing from stereo stem feeds
- Onboard Wing-inspired reverb and built-in stereo ambience microphones for adding space to dry input signals
- 1-knob, per-channel Tilt-EQ provides easy tonal adjustment
- Adjustable limiter certifies safe monitoring levels
- StageTalk intercom operability
- Return channels allow routing personal mixes back to a P24Hub for connection to wireless IEM transmitters
- Analog stereo auxiliary input accommodates local sources, such as a click track, on a 1/4-in. TRS connector
- External dynamic mic input for giving cues to bandmates or communicating with the mix engineer
- Footswitch input facilitates hands-free talkback operation
- Provides pristine, low-latency audio up to 24-bit/48kHz
- Stable operation range of more than 130 ft. over a single XLR cable
- DC power supply allows you to daisy-chain two or more P24 mixers
- Enough power to drive lo-Z headphones and IEMs in loud environments
Specs
| StageConnect HOST/Master |
1 x male |
| StageConnect CLIENT/Slave |
1 x female |
| Phones |
1/4" TRS, stereo |
| Line out |
1/4" TRS, mono |
| Aux in |
1/4" TRS, stereo |
| Footswitch |
1/4" TS |
| Talkback |
XLR female |
Controls
| Tone |
±12 dB tilt EQ |
Headphone Mix Parameters
| Tone |
±12 dB tilt EQ |
| Reverb |
OFF, -59 dB to +20 dB |
| Limiter |
Threshold: 0 dB to -20 dB |
| Mid gain |
-12 dB to +6 dB, semi-parametric |
| Mid frequency (Hz) |
100, 125, 160, 200, 250, 310, 400, 500, 630, 800, 1000, 1250, 1600, 2000, 2500, 3100, 4000, 5000, 6300, 8000, 9500 |
Power
| Power consumption |
9 W |
| Mains connection |
Phantom power over StageConnect or external power supply |
Dimensions/Weight
| Dimensions (H x W x D) |
77 x 214 x 185 mm (3.0 x 8.4 x 7.3") |
| Weight |
1.08 kg (2.38 lbs) |
